Mobil SHC™ Rarus Series

Name: Mobil SHC™ Rarus Series
Brand: Mobil
Rating: 0 (0 reviews)

Supreme Performance Air Compressor Lubricant

Mobil SHC™ Rarus Series oils are supreme performance air compressor lubricants primarily intended for the lubrication of severe duty rotary screw and vane air compressors. They are particularly suited for severe service where synthetic oil-based products are not meeting expectations such as in severe applications subjected to high final compression temperatures or where extended oil drain intervals are desired. Mobil SHC Rarus Series formulation provides the potential to deliver up to 3 times oil drain interval versus a leading synthetic compressor lubricant.

Our Mobil SHC™ Rarus Series synthetic air compressor oils protect vane and rotary screw air compressors. They are designed for severe service – such as high final compression temperatures or extended oil drain intervals – where other synthetic oils do not meet service life expectations.

Mobil SHC Rarus Series synthetic air compressor oils are formulated to deliver up to three times longer oil drain intervals than other synthetic air compressor lubricants. In fact, Mobil SHC Rarus oils have even demonstrated the ability to perform for up to 24,000 hours in field tests. These oils can also:

Minimize need for maintenance and downtime
Enhance safety through exceptional durability
Support sustainability efforts with extended oil drain intervals
Boost productivity while protecting your equipment

Minimizes costs and delays of air compressor maintenance
Up to 24,000 hours of lubricant life, backed by a three-year warranty*
Long equipment life due to wear, rust and corrosion protection
Outstanding protection, even under extreme service conditions

Download PDS

Talk to an expert

Find Distributor

Add up your savings

Use our calculator tools to estimate your operation’s potential savings for upgrading your conventional lubricant to Mobil SHC™ oil or grease. Then contact an ExxonMobil engineer or authorized dealer to further refine your estimate.

Product series information

Air compressors productivity pointer386.24 KB

pdf

Mobil SHC™ Rarus Series performance profile

Narrow your results by using the filters below

{{ var imageURL = raw.imageurl }} <%if(imageURL != null && imageURL!='') {%> <%if(imageURL.indexOf("{")>=0) {%> {{ var formattedUrl=(imageURL.replace("{","").replace("}",".ashx")) var urlWithAltText= "img"+" alt" formattedUrl =formattedUrl.replace("img",urlWithAltText) }} <%=formattedUrl%> <% } else { %> <img src="<%- imageURL%>" alt="" class="CoveoImageIcon" /> <%}%> <% } else { %> Mobil group of barrels

<% } %> <% if (hasHtmlVersion) { %>

<% } %>

<% if (coveoFieldValue("HasLayout") === "1" || raw.syssource !== currentSourceName()) { %> <%= title ? title : clickUri %>
<%= raw.productdescription%>
<%= raw.marketindustrialproducttypeandfeature %> <% } else { %> <%= title ? title : '' %>
<%= raw.productdescription%>
<%= raw.marketindustrialproducttypeandfeature %> <% } %>

<% if (coveoFieldValue("HasLayout") === "1" || raw.syssource !== currentSourceName()) { %> <% if (raw.resulttype === "Product") { %> Product details and SDS <% } else { %> Product Series <% } %> <% } else { %> <% if (raw.resulttype == "Product") { %> Product <% } else { %> Product Series <% } %> <% } %>

Technical resources

Flushing oil-flooded rotary screw air compressors | Mobil™
Flushing oil-flooded rotary screw air compressors before switching lubricants is critical in preventing incompatibility issues.

Technical topics

Features and Benefits

• Outstanding thermal / oxidation stability help to provide up to three times oil drain interval versus a leading synthetic compressor oil and reduce maintenance downtime

• Excellent varnish and sludge control helps to deliver cleanliness and extended compressor oil life

• High performance synthetic base stocks with high viscosity index enables wide temperature range capability and effective lubrication at high temperatures

• High load carrying capability protects equipment and extends life, helps minimize unexpected downtime and extend service periods

• Exceptional resistance to rusting and corrosion, very good antiwear, demulsibility, foam control and air release and multi-metal compatibility

• Excellent water separability helps reduce carryover to downstream equipment, reduce sludge formation in crankcases and discharge lines, helps reduce blockage of coalescers, coolers and less potential for emulsion formation

Applications

• Mobil SHC Rarus Series are primarily for rotary screw and vane air compressor, very effective in screw type compressors with oil injection cooling; compressors with a history of excess oil degradation, poor valve performance or deposit formation

• Compressors operating under severe conditions, particularly effective for continuous high temperature operation with discharge temperatures up to 200ºC

• Compressor systems with critical gears and bearings

• Not for air compressors used in breathing air applications

• Compatible with all metals used in compressor construction and with conventional mineral oil-based air compressor oils but mixture with other oils may detract from the total performance capability

Properties and Specifications

Property	32	46	68
Grade	ISO 32	ISO 46	ISO 68
Color, Visual	Orange liquid	Orange liquid	Orange liquid
Copper Strip Corrosion, 24 h, 100 C, Rating, ASTM D130	1B	1B	1B
Flash Point, Pensky-Martens Closed Cup, °C, ASTM D93	204	197	192
Kinematic Viscosity @ 100 C, mm2/s, ASTM D445	5.6	7.1	9.7
Kinematic Viscosity @ 40 C, mm2/s, ASTM D445	30.6	44.1	65.3
Pour Point, °C, ASTM D5950	-42	-45	-39
Rust Test, Synthetic Sea Water, 24 h @ 60 C, ASTM D665-PROB	PASS	PASS	PASS
Specific Gravity, 15 C/15 C, ASTM D1298	0.878	0.868	0.865
Viscosity Index, ASTM D2270	123	122	129

Health and Safety

Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
