Mobil Rarus™ PE Series - Ethylene compressor oil

Ethylene compressor oil

Mobil Rarus™ PE R-A, R-B, R-C and R-D 220​

Mobil Rarus™ PE R-A, R-B, R-C and R-D 220 are viscous, colourless oils of ISO viscosity grade 220, specifically designed for the lubrication of very high pressure ethylene compressors. They are based on high purity, saturated hydrocarbon oils (white oils), supplemented with friction reducing and free-radical trap additives at adapted treat levels.



In the production of polyethylene, high-speed reciprocating compressors are used to compress ethylene gas to high pressures up to 3000bar. In these applications, the compressor lubricant can come in contact with the polyethylene in the polymerization process.  Under these circumstances, the lubricating oil required must be of acceptable purity and be known not to modify the properties of the polyethylene.



Mobil Rarus PE R-A, R-B, R-C and R-D 220 provides good lubrication of the compressor cylinders and are compatible with the polyethylene process.  They can be used to produce polyethylene where food contact can occur such as in food packaging.  Mobil Rarus PE R-A, R-B, R-C and R-D 220 have good thermal and chemical stability.  They can be used up to 3000 bars, according to injection system and temperature.  Reactive gas components and impurities may react into the compressor itself, with formation of sludge, which may lead to lubrication failure. This is prevented by the additives, which also reduce bushing wear.



Mobil Rarus PE R-A 220 is recommended with highly reactive gas components.



Mobil Rarus PE R-B 220 is recommended for low reactivity impurities. Its additives display low volatility and migration. It is well suited for applications where there is fatty food contact



Mobil Rarus PE R-C 220 is recommended for intermediate reactivity gases.



Mobil Rarus PE R-D 220 is recommended for specific highly severe, high pressure applications.



{0} offers {1} lubricant grades

Features and Benefits

Mobil Rarus PE R-A, R-B, R-C and R-D 220 are specifically engineered to help provide long and trouble-free compressor performance. Mobil Rarus PE R-A, R-B, R-C, and R-D 220 products are NSF H1 registered for food machinery "Lubricants for Incidental Contact with Food", and meet the requirements for lubricants with incidental food contact (FDA 21 CFR 178.3570) and processing aids used in the production of olefin polymers compliant with FDA 21 CFR Title 21 ch.1 177.1520.

Mobil Rarus PE R-A, R-B, R-C and R-D 220 compressor oils offer the following benefits:

•  Suitable for applications where they can come in contact with food

•  High purity levels so that they will not modify properties of polyethylene

•  Excellent cylinder lubricant helping to prolong compressor life

•  Good thermal and chemical stability resulting in lower deposits and longer oil life



Features

Advantages and Potential Benefits

High neutrality and low reactivity components

Do not interfere with catalytic polymerization reactions

High purity components

Do not induce any discolouration or odor in the final polymer

Components approved for food contact

Suitable for the manufacture of polymers for food packaging

Low polarity

Suitable in the manufacture of polymers for electrical insulation and thin bags (plastic bags)

Premium quality products

Reduced maintenance shutdowns



Applications

Mobil Rarus PE R-A, R-B, R-C and R-D 220 have the following applications:

     •  High pressure ethylene compressors

     •  Compressors used in the production of polyethylene used in food contact applications



Specifications and Approvals



This product is registered to the requirements of:

R-A 220

R-B 220

R-C 220

R-D 220

NSF H1

X

X

X

X



This product meets or exceeds the requirements of:

R-A 220

R-B 220

R-C 220

R-D 220

Burckhardt VSB 1001180

X



X



FDA 21 CFR 178.3570

X

X

X

X



Properties and Specifications

Property

R-A 220

R-B 220

R-C 220

R-D 220

Grade

ISO VG 220

ISO VG 220

ISO VG 220

ISO VG 220

Acid Number, mgKOH/g, ASTM D974

6.1

6.1

6.1



Density @ 15 C, kg/l, ASTM D4052

0.878

0.874

0.876

0.872

Flash Point, Cleveland Open Cup, °C, ASTM D92

210

210

210

200

Kinematic Viscosity @ 40 C, mm2/s, ASTM D445

220

226

226

220

Pour Point, °C, ASTM D97

- 12 max

- 12 max

- 12 max

- 12 max

Saybolt Color, ASTM D156

+21 min

+24 min

+24 min

+24 min

Water Content, mg/kg, ASTM D6304

50

50

50





Health and Safety

Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
