Mobil Zerice S Series

Refrigeration Compressor Lubricants

Mobil Zerice™ S Seires

Mobil Zerice S Oils are premium quality synthetic refrigeration compressor lubricants based on alkyl benzenes, which due to their nature, have superior miscibility with hydrochlorofluorocarbon (R22). This allows them to be used in very low temperature applications, down to -60°C. In certain circumstances, they can also be used in compressors where ammonia acts as the refrigerating fluid.



{0} offers {1} lubricant grades

Technical Resources

Features and Benefits

Relative to mineral and other synthetic lubricants, Mobil Zerice S has superior solubility with halocarbon refrigerants. This helps avoid the common problem of oil separation and congealing on the valve and heat transfer surfaces of the refrigeration system.



Additionally, Mobil Zerice S lubricants have very low pour and floc points which helps prevent harmful wax precipitation that can block expansion valves and heat transfer surfaces.



The synthetic nature of Mobil Zerice S lubricants provides excellent chemical stability which resists reaction with refrigerants, as well as high thermal stability which helps prevent oil breakdown.



Features

Advantages and Potential Benefits

Miscibility with halocarbon refrigerants

Increased system efficiency

Low pour and floc points

Avoids wax precipitation and increased system efficiency

Chemical Stability

Long oil service life



Applications

Mobil Zerice S lubricants are recommended for all refrigeration compressor types: reciprocating or rotary screw. They are well suited for use with hydrochlorofluorocarbon refrigerants, and may also be suited for use with ammonia in certain equipment builders' compressors. They should not be used with sulfur dioxide or R134A refrigerants. The specific viscosity grade should be selected in accordance with the compressor manufacturer's recommendations.



Properties and Specifications

Property

32

46

68

100

Grade

ISO 32

ISO 46

ISO 68

ISO 100

Acid Number, mgKOH/g, ASTM D974

0.05

0.05

0.05

0.05

Copper Strip Corrosion, 3 h, 100 C, Rating, ASTM D130

1

1

1

1

Flash Point, Cleveland Open Cup, °C, ASTM D92

154

154

174

186

Kinematic Viscosity @ 40 C, mm2/s, ASTM D445

32

46

68

100

Pour Point, °C, ASTM D97

-33

-30

-27

-27

R12 Flocculation Point, °C, AMS 100.42

-60

-60

-60

-60

Water, ppm, ASTM D1533

<30

<30

<50

<30



Health and Safety

Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
