Mobil Hydraulic AW Series

Hydraulic Oils

MobilTM Hydraulic AW Series

Mobil™ Hydraulic AW Series oils are good quality anti-wear hydraulic oils intended for industrial and mobile service applications, subjected to moderate operating conditions and requiring anti-wear lubricants.

Products Mobil Hydraulic AW 32/46/68  meet the claim by DIN 51524-2: 2017-06 and could be used where HLP 32/HLP 46/HLP 68 hydraulic oils are required.



Equipment lubricant recommendations

Our Mobil Serv℠ Product Selector tool will help you identify lubricant(s) for your specific equipment.

Data sheets

Features and Benefits

•  Good anti-wear performance helps reduce pump wear and prolonging pump life

•  Corrosion protection helps reduce the effects of moisture on system components

•  Filterability to prevent filter blockage even in the presence of water



Applications

•  Systems using gear, vane, radial and axial piston pumps and those containing gears and bearings where mild anti-wear characteristics are required

•  Where hydraulic oil contamination or leakage is unavoidable

•  Where small amounts of water are unavoidable



Specifications and Approvals

This product meets or exceeds the requirements of:

MOBIL HYDRAULIC AW 32

MOBIL HYDRAULIC AW 46

MOBIL HYDRAULIC AW 68

DIN 51524-2:2017-06

X

X

X



Properties and Specifications

Property

MOBIL HYDRAULIC AW 32

MOBIL HYDRAULIC AW 46

MOBIL HYDRAULIC AW 68

Grade

ISO 32

ISO 46

ISO 68

Copper Strip Corrosion, 3 h, 100 C, Rating, ASTM D130

1A

1A

1A

Density @ 15 C, kg/l, ASTM D4052

0.87

0.87

0.88

Emulsion, Time to 3 mL Emulsion, 54 C, min, ASTM D1401

15

20

20

Flash Point, Cleveland Open Cup, °C, ASTM D92

210

225

234

Kinematic Viscosity @ 40 C, mm2/s, ASTM D445

32

44

63

Pour Point, °C, ASTM D97

-24

-24

-18

Viscosity Index, ASTM D2270

95

95

95



Health and Safety

Health and Safety recommendations for this product can be found on the Material Safety Data Sheet (MSDS) @ http://www.msds.exxonmobil.com/psims/psims.aspx
